Rail Size Chart
|
Door Opening Size (Width) |
Recommended Rail Size (Length) |
|
24 In. |
4.5 Ft. |
|
28 In. |
5.5 Ft. |
|
30 In. |
5.5 Ft. |
|
32 In. |
6 Ft. |
|
36 In. |
6.6 Ft. |
|
38 In. |
7 Ft. |
|
40 In. |
7.5 Ft. |
|
42 In. |
7.5 Ft. |
|
For all other Door Opening Sizes, use this formula to find the Recommended Minimum Rail Length (Single Rails Only) |
(Door Opening * 2) + 6" (Round up to the nearest half-foot) |
| For Bypass Systems, use this formula to find the Recommended Minimum Rail Length | (Door Opening + 6") |
